Lead Ingot Txias Tej Tshuab

Cov ntaub ntawv khoom

Lead Ingot Cold Cutting Tshuab yog tsim los ntawm txhuas ingot conveyor, slicer, lead ncuav mog qab zib cutter, lead bulk conveyor, roj twj tso kua mis (roj dawb) thiab tswj vaj huam sib luag. Thib ob, peb muab lub ingot rau ntawm lub conveyor thiab nkag mus rau lub turnover mechanism. Thaum cov ingots raug txiav rau hauv 20 hli tuab blocks los ntawm lub slicer, lawv tau ua rau 23 * 23 * 20mm bulk aluminium blocks thiab khaws cia rau hauv lub silo ntawm lub pob zeb. Qhov tseem ceeb tshaj, tag nrho peb cov tshuab yog compact hauv kev tsim thiab tsim nyog hauv cov qauv. Thaum kawg, yog tias koj txaus siab rau peb cov khoom, thov hu rau peb raws sijhawm.

Khoom Feature

Lead Ingot Txias Txiav Tshuab tuaj yeem xa cov hlau lead ingots thiab pwm extrusion. Qhov thib ob, cov hmoov txhuas yog yuav luag cubic. Tsis xav tau txhuas ingot melting, kev ua haujlwm siab, txuag hluav taws xob, kev tiv thaiv ib puag ncig, tsis muaj cov pa taws ua rau hmoov lead, hmoov lead slag. Lub tshuab muaj txhuas ingot conveyor, slicer, lead ncuav mog qab zib cutter, lead bulk conveyor, roj twj tso kua mis (tsis muaj roj) thiab tswj vaj huam sib luag. Qhov tseem ceeb tshaj, kev siv peb cov khoom txuag hluav taws xob. Thaum kawg, peb cov khoom muaj cov yam ntxwv ntawm kev ua haujlwm yooj yim, peb muaj kev tswj xyuas ntse, kev ua haujlwm ntawm ib lub pob.

Parameter

1) Lead Ingot Conveyor:

Lub cev muaj zog: 0.4kW;

Tus nqi xa khoom: Max 10nos lead ingot per;

Lead Ingot Loj: L610mm, Hauv qab Dav 120mm, Qhov siab 85mm

2) Slicing tshuab:

Slice Thickness: 14-20 hli djustable

Max Ntau Lawm: -2t/h

Lub Zog: 11kW

3) Lead Bulk Trimming Tshuab:

Lead Bulk Loj: -23 × 23 × 20mm

Max ntau lawm: 2t / h

Lub cev muaj zog: 4kW

4) Tag nrho cov khoom: 2t / h

5) Kev siv hluav taws xob tag nrho: -16kW

Installation Requirement:

1) Cov neeg siv khoom yuav tsum muab 1 teeb hluav taws xob Hoist rau kev pub mis.

2) Pls npaj thaj tsam 4m * 4m rau kev teeb tsa.

3) Cov neeg siv khoom yuav tsum npaj cov Hluav Taws Xob (AC 380V), Compressed Cua (0.4-0.6MPa, 3L / min), Cov dej txias rau qhov chaw ntawm lub tshuab.

4) Cov neeg siv khoom yuav tsum muab cov roj hydraulic (200L) raws li kev siv tshuab ua haujlwm.

Muab piv rau Cov Txias Chamber Bulk Pelletizing Tshuab tshiab nrog cov tsoos Casting Tshuab, tsis tas yuav muaj cov hmoov txhuas / cov twj tso kua mis / Lub tshuab ua haujlwm ntau nrog hauv qab kom zoo dua.

1) Tsis muaj cov khoom pov tseg.

2) Tsawg zog xav tau nrog cov nqi tsim khoom tsawg.

3) Tsis muaj txhuas fume, tsis muaj peev txheej ntawm Environmental khoom.

4) Tsis tas yuav hloov lub lauj kaub ua kom sov, txo tus nqi.

Cim npe nrov: txhuas ingot txias txiav tshuab
